Thermo-Electra MI 1038 Fixed insertion thermocouple probe

Product Code: MI1038

Thermocouples with connection head are specifically designed for heavy-duty temperature sensing applications like ovens, machines, and industrial environments where their robust construction ensures a prolonged sensor life. Thermo-Electra produces thermocouples according to the highest standards and offers the best quality for every application.

Features
Downloads

Construction	Mineral insulated
Material	SS 316 – (Wst 1.4401) standard, other materials possible
Insertion length	Customer to specify
Process connection	M20x1.5m 1/2″BSP (G1/2″), 1/2″NPT or other threads possible

Mechanical	To fit M20x1.5, 1/2″BSP (G1/2″), 1/2″NPT or other threads
Electrical	Insulated PTFE wires 180°C
Wire length	150 mm
Construction	fixed insertion
Sensor	Nipple seal welded to the sensor sheath

Calibration	K, T, J, E, N, U or L
For duplex	KK, TT, JJ, EE, NN, UU or LL
Accuracy	According IEC 60584
Hot junction	Insulated
Insulation material	Mineral insulated ( MgO )
Ingress protection	Tested with 500 Vdc @ 20°C
Insulation resistance	Minimum 100 M ohm

Hot junction	Grounded hot junction
Diameter	Other sheath or tip diameter
Material	Other sheath material
Thread	Other thread size

Datasheet
