Müller Transmitter Standard Signal for DIN Rail (SP-DR)
Click to enlarge

Müller Transmitter Standard Signal for DIN Rail (SP-DR)

Müller Transmitter Standard Signal for DIN Rail (SP-DR)

Product Code: SP-DR

Manufacturer: Müller


The Müller Transmitter Standard Signal for DIN Rail (SP-DR) is suitable in all areas where a standard input signal has to be converted in an output signal of 4…20 mA with galvanic insulation. It is operated in a 2-wire current loop and can be customised on the application with a RFID configurator and an additional software.

  • Input current: 0…20 mA – Input Voltage: 0…20 V
  • Input resistance; 0…4000 ohms
  • Output: 4…20 mA, galvanical insulation
  • Supply: 6…32 VDC out of current loop
  • Transmission error: 0,1% FS
  • Configuration: RFID-Programmer
  • Connection: Terminal screws
  • Protection: IP20
  • Dimensions: 18xs90x64 mm
  • Enclosure: Synthetics black
Datasheet Download
