Müller Strain Gauge Bridge Amplifier (SMM-DR)
Click to enlarge

Müller Strain Gauge Bridge Amplifier (SMM-DR)

Müller Strain Gauge Bridge Amplifier (SMM-DR)

Product Code: SMM-DR

Manufacturer: Müller

Enquire

The Müller Strain Gauge Bridge Amplifier (SMM-DR) with 1 sensor input is for use in applications where a bridge signal has to be observed because of reasons of safety, e.g. for stage technology. The evaluation of the load cell has to be done with a control system which is approved for SIL3 / Performance Level ‘e’

  • Sensor input: 1x strain gauge full bridge (350 ohms)
  • Stain gauge sensitivity: up to 4 mV/V
  • Bridge supply: 5 VDC
  • Analog output: 2x 4…20 mA
  • Voltage supply: 24 VDC +/-10%
  • Accuracy: 5% deviation channel A / channel B
  • Protection: IP20
  • Diagnostic input: Test pulse 24 VDC
  • Enclosure: DR22,5 (117,2×22,5×113,6)
  • Certificate: SIL 3, Performance Level “e”
Datasheet Download
Instruction Manual Download
